Oil Temperature Gauge 120°C
The VDO Oil Temperature Gauge 120°C is a precision instrument designed to measure engine oil temperature up to 120 degrees Celsius. It features a clear, easy-to-read display, providing accurate and reliable readings essential for monitoring engine health. Ideal for automotive and marine applications, this gauge helps prevent engine overheating and ensures optimal performance by allowing for precise temperature management. The VDO Oil Temperature Gauge 120°C combines durability with high functionality, making it a crucial tool for maintaining engine efficiency and longevity.
Specification:
- Colour: Black
- Panel hole diameter: 52 mm - 2 1/16"
- Scale : +20°C to +100°C
- Operating voltage: 24 Volt DC
- Retail package 1 Temperature gauge
Sizes and mounting:
| Installation (Hole) diameter and Outside diameter: |
52 mm - 2 1/16 Inch en 59.25 mm - 2 1/3 Inch |
| Installation depth: |
67.5 mm |
| Locking height with Spinlock nut: |
Not available |
| Locking height with bracket: |
0.5 mm - 8 mm |
| Flushmount: |
None |
Functionality:
| Oil temperature range: |
+20°C to +100°C |
| Sensor signal oil temperature gauge: |
VDO NTC Thermistor 700-38.5 Ohm |
| Accuracy: |
Not specified by VDO |
| Connection: |
AMP Male blade connector 6,3 x 0,8mm (3x) |
| Illumination connection: |
AMP Male blade connector 6,3 x 0,8mm (2x) |
Power supply:
| Operating voltage: |
21.5 - 30 Volt DC |
| Current consumption without illumination: |
131 mA |
| Reverse polarity protection: |
Yes |
| Short circuit protection: |
Not specified by VDO |
Dial & Pointer:
| Deflection angle: |
90° |
| Dial colour: |
Black |
| Dial Illumination: |
Floodlight 24V - 2 Watt White - Green - Red |
| Pointer: |
Red backlight |
| Warning indication: |
None |
| Programming: |
None |
Design:
| Model: |
Cockpit International |
| Lens: |
Single - Anti-glare |
| Standard bezel: |
Triangular black (Threaded ring) |
Protection and standards:
| Front protection class: |
IP64 (DIN 40050) - Ozon proof - UV proof |
| Rear protection class: |
IP42 (DIN 40050) |
| Relative humidity: |
Not specified by VDO |
| Operating temperature: |
-30°C to +85°C |
| CE standard: |
Yes |
| DNV GL Certification: |
Not specified by VDO |
| Mechanical shock 8 hours: |
Max: 1G - 25Hz - 2000Hz |
| EMC test: |
According to EN 13309 and ISO 13766 |
| Nominal position: |
NL 0 to NL 90 - DIN 16257 |
| Housing: |
Plastic flame retardant |
OEM (10 pieces) package:
- VDO Cockpit International 310-040-022C Temperature gauge
- Steel bracket zinc-plated and chromatized
- Connecting material order separately
